This article is about the stand-alone product.
  • If you are looking for information about using remote video assistance in the Resco platform, see Houston video calls.
  • If you are looking for information about using guides in the Resco platform, see Guides.
Warning The standalone product resco.Houston is no longer supported. The knowledge library function continues as Guides in the Resco platform. Should you have any questions, please contact

resco.Houston is a product for frontline workers introduced in June 2021. It provides a knowledge library and augmented-reality remote assistance calls in a single app.


  • Increase operation efficiency and safety
  • Solve problems right on the spot
  • Ensure continuous improvement and preserve tribal knowledge


  • Secure backend cloud server that stores your company knowledge and other data
  • A mobile app for front-line workers
  • A web app for the experts, managers, and admins working from a PC


resco.Houston offers a different experience depending on your role in the company.

Mobile user

Mobile users have access to the mobile app on the floor as a vital source of information about equipment. As a mobile user, you can:

  • Login to the app using your name and password, or by scanning a QR code.
  • Locate the right piece of equipment in the app, either by selecting it from the full list of equipment, using a quick search to narrow down the list, or scanning a QR code from the equipment.
  • Access the equipment detail page that displays all important information about the equipment, along with a list of guides and a list of experts.
  • Read guides to learn how to install, operate, maintain, or repair the equipment.
  • If the guides are not sufficient to solve a problem, use an augmented-reality video call to connect with a remote expert.
  • Create guide drafts: take photos in the field and enter brief instructions. Knowledge manager can then take over, provide additional details, and finally publish the guide.


Experts provide assistance to junior colleagues remotely using AR video calls. As an expert, you can:

  • Start a web browser, log in to using your credentials.
  • Have read-only access to company data from the web application.
  • As long as you have notifications enabled, you can be reached by video calls, accept them on your PC.
  • During the call, you have access to several visual tools. You can draw freely into the AR scene or use 3D arrows to draw attention to important parts.
  • If the toolbar obstructs your view, you can drag it away.

Knowledge Manager

Knowledge managers create the content. As a knowledge manager, you can:

  • Using a web browser, log in to using your credentials.
  • Add new machine models to the database: enter a name, description, manufacturer, and a photo. Once the record is saved, you can associate guides and experts with the model.
    Note: A model is a machine by a manufacturer.
  • Add new equipment to the database: enter a name, serial number, description, ID, and photo; select a model, select who installed it. Again, once the record is saved, you can link guides and experts.
    Note: Equipment is a machine with a particular location, setup, and configuration.
  • Add new guides: Include a cover photo, title, cover description, and select a state. Upload media to the guide, add text, notes, and warnings as needed.


Has access to the backend server via Admin Console. As an admin, you can:

  • Using a web browser, log in to using your credentials.
  • Manage users, teams, business units, ...


The resco.Houston product is built on the flexible resco.ServicePlatform. As such, it can benefit from many integration options inherently available on the platform. For example, you can use the Resco Cloud connector for Power Automate to connect to many third-party services. One of such integrations is described here: Migrate models and equipment from Dynamics to resco.Houston.

Launch Houston from Resco Mobile CRM

In some scenarios, you might wish to mix Resco Mobile CRM with resco.Houston. Use the following procedure to add a button to the Customer Asset form of your Resco Mobile CRM with Dynamics backend. Resco Mobile CRM users can tap the button to open the same asset in resco.Houston.

<!DOCTYPE html>
    <meta charset="utf-8" />
    <title>JS from Resco rules</title>
    <meta http-equiv="X-UA-Compatible" content="IE=edge" />
      content="initial-scale=1, minimum-scale=1, maximum-scale=1, user-scalable=no"
    <script type="text/javascript" src="../JSBridge.js"></script>
      function openUrl(entityForm) {
  1. Take the script above and save it as an HTML file, for example, openLink.html.
  2. Download Resco JavaScript library from Resco GitHub.
  3. Edit the app project in Woodford and go to Offline HTML.
  4. Upload the files JSBridge.js and openLink.html to your offline HTML folder.
    The script assumes that the HTML file is in a subfolder related to the JSBridge file. Make sure to update the path if you organize your files differently.
    Add openLink script to offline html.png
    Save all changes.
  5. Edit the Customer Asset form.
  6. Add an iframe, specify its name, and set the Url to point to a file created earlier. Leave all 3 checkboxes cleared. Click OK.
    Configure iframe.png
  7. Add a button to the form. Feel free to change anything to match your needs.
    Add button to form.png
  8. Click Button Click and add a rule to execute our script. In the first line, replace "Button1" to match the Binding of your button.
    Edit the button click rule.png
  9. Save everything, publish the app project, and test the new button in your Resco Mobile CRM app.
